Flexi 15 – VNSN (10001200)

• Flexi 15VN can work in as little as 1.6m/63" aisles (ISO pallet) or 1.8m/71" (Euro Pallet).
• Convert existing costly guided very narrow aisle operations, eliminate double handling. No guide rails needed.
• Full 230° over-rotation, maximum aisle clearance and manoeuvrability, one turn operation.
• Lifts heights to over 8.0m/315".
• Unique compact front axle – Maximise stacking aisle clearance, twin front-wheel drive.
• Digital brushless motor technology on steering, travel and lift reduces average power consumption by 20%.
• Independent 1.8KW power steering motor conserves battery energy, very low noise level and no kickback.
• Elastic rubber treaded tyres on all wheels, for use on all floor surfaces with long service life.
• Three ‘brushless’ digital electric motors AC inverter controlled for long battery life and ultra-low servicing costs.

  • NOMINAL CAPACITY 1500kg – 2000kg
  • MAXIMUM LIFT HEIGHT 8.6m
  • AISLE WIDTH 1.6m – 1.8m
  • CHASSIS WIDTH 1000mm – 1200mm
